EW-797
Tri-Band Wi-Fi 7 Mesh Router · 10G WAN
The EFOCE EW-797 is a Tri-Band Wi-Fi 7 Mesh Router · 10G WAN.
Overview
Intro
The EFOCE EW-797 is a Tri-Band Wi-Fi 7 Mesh Router · 10G WAN.
Overview
Tri-Band Wi-Fi 7 Mesh Router · 10G WAN.
Highlights
- Wi-Fi generation: WIFI 7
- Radio band: band 2 4 ghz; maximum PHY rate 1030 Mbps
- Radio band: band 5 ghz; maximum PHY rate 2880 Mbps
- Radio band: band 6 ghz; maximum PHY rate 5760 Mbps
- 1 RJ45 wan interface(s); maximum link rate 10000 Mbps
- 4 RJ45 lan interface(s); maximum link rate 1000 Mbps
- 1 DC_JACK power interface(s)
- 1 USB_A storage interface(s)
- 1-Pack configuration
Specifications
Wireless
Mesh Protocols
easymesh
Ethernet Backhaul
yes
Wireless Backhaul
yes
Wi-Fi Generation
wifi_7
Multi-Link Operation (MLO)
yes
4K-QAM
yes
Wi-Fi Security
wpa3_personal
Radios
Frequency Band
band_2_4_ghz
Max. PHY Rate
1030 Mbps
Max. Channel Width
40 MHz
Spatial Streams
3
Max. SSIDs
8
Frequency Band
band_5_ghz
Max. PHY Rate
2880 Mbps
Max. Channel Width
160 MHz
Spatial Streams
2
Max. SSIDs
8
Frequency Band
band_6_ghz
Max. PHY Rate
5760 Mbps
Max. Channel Width
320 MHz
Spatial Streams
2
Max. SSIDs
8
Interfaces
Interface Type
rj45
Interface Role
wan
Quantity
1
Max. Link Rate
10000 Mbps
Interface Type
rj45
Interface Role
lan
Quantity
4
Max. Link Rate
1000 Mbps
Interface Type
dc_jack
Interface Role
power
Quantity
1
Interface Type
usb_a
Interface Role
storage
Quantity
1
Hardware
Product Type
mesh_wifi_system
Hardware Revision
V1.0
Applicable Technical Scope
eu
RAM
512 MB
Flash Storage
256 MB
Network & Management
Connection Mode
wireless
Connectivity Technologies
ethernet, wifi
Management Protocols
web, telnet, ssh, tr_069, app
IPv6
yes
Guest Network
yes
Parental Controls
yes
Max. Connected Devices
128
Power Inputs
Power Input Type
external_adapter
Packs & Package Contents
EW-797(1-Pack)
Units per Pack
1
Package Contents
Item Type
product
Quantity
1
Item: EW-797
Item Type
power_adapter
Item
Power Adapter
Quantity
1
Item Type
cable
Item
Ethernet Cable
Quantity
1
Item Type
qig
Item
Quick Start Guide
Quantity
1
