EW-630
Wi-Fi 6 AX3000 Mesh Router · Gigabit
The EFOCE EW-630 is a Wi-Fi 6 AX3000 Mesh Router · Gigabit.
Overview
Intro
The EFOCE EW-630 is a Wi-Fi 6 AX3000 Mesh Router · Gigabit.
Overview
Wi-Fi 6 AX3000 Mesh Router · Gigabit.
Highlights
- Wi-Fi generation: WIFI 6
- Wi-Fi class: AX3000
- Radio band: band 2 4 ghz; maximum PHY rate 573.5 Mbps
- Radio band: band 5 ghz; maximum PHY rate 2402 Mbps
- 1 RJ45 wan interface(s); maximum link rate 1000 Mbps
- 3 RJ45 lan interface(s); maximum link rate 1000 Mbps
- 1 DC_JACK power interface(s)
- 1-Pack configuration
Specifications
Wireless
Wi-Fi Generation
wifi_6
Wi-Fi Class
AX3000
Radios
Frequency Band
band_2_4_ghz
Max. PHY Rate
573.5 Mbps
Antenna Gain
3 dBi
Spatial Streams
2
Antenna Type
internal
IEEE Standards
802.11b, 802.11g, 802.11n, 802.11ax
Frequency Band
band_5_ghz
Max. PHY Rate
2402 Mbps
Max. Channel Width
160 MHz
Antenna Gain
3 dBi
Spatial Streams
2
Antenna Type
internal
IEEE Standards
802.11a, 802.11n, 802.11ac, 802.11ax
Interfaces
Interface Type
rj45
Interface Role
wan
Quantity
1
Max. Link Rate
1000 Mbps
Interface Type
rj45
Interface Role
lan
Quantity
3
Max. Link Rate
1000 Mbps
Interface Type
dc_jack
Interface Role
power
Quantity
1
Hardware
Product Type
mesh_wifi_system
Hardware Revision
V1.0
Applicable Technical Scope
eu
RAM
256 MB
Flash Storage
16 MB
Network & Management
Connection Mode
wireless
Connectivity Technologies
ethernet, wifi
Operating Modes
router, bridge
Management Protocols
web, tr_069
IPv6
yes
Guest Network
yes
Parental Controls
yes
Band Steering
yes
Max. Connected Devices
128
VPN Client Protocols
L2TP, PPTP
Power Inputs
Power Input Type
external_adapter
Electrical Type
dc
Input Voltage (Min.)
12 V
Input Voltage (Max.)
12 V
Input Current (Max.)
1 A
Environment
Operating Temperature (Min.)
-10 °C
Operating Temperature (Max.)
45 °C
Operating Humidity (Min.)
10 %
Operating Humidity (Max.)
90 %
Storage Temperature (Min.)
-20 °C
Storage Temperature (Max.)
70 °C
Storage Humidity (Min.)
5 %
Storage Humidity (Max.)
90 %
Packs & Package Contents
EW-630(1-Pack)
Units per Pack
1
Package Contents
Item Type
product
Quantity
1
Item: EW-630
Item Type
power_adapter
Item
Power Adapter
Quantity
1
Item Type
cable
Item
Ethernet Cable
Quantity
1
Item Type
manual
Item
User Manual
Quantity
1
