ES-F08PX
10-Port Fast Ethernet PoE Switch · 8× PoE + 2× Uplink
The EFOCE ES-F08PX is a 10-Port Fast Ethernet PoE Switch · 8× PoE + 2× Uplink.
Overview
Intro
The EFOCE ES-F08PX is a 10-Port Fast Ethernet PoE Switch · 8× PoE + 2× Uplink.
Overview
10-Port Fast Ethernet PoE Switch · 8× PoE + 2× Uplink.
Highlights
- 8 RJ45 downlink interface(s); maximum link rate 100 Mbps
- 2 RJ45 uplink interface(s); maximum link rate 100 Mbps
- 1 AC_INLET power interface(s)
- 1-Pack configuration
Specifications
Switching
Switching Capacity
2000 Mbps
Forwarding Rate
1.488 Mpps
Surge Protection (Common Mode)
4 kV
Surge Protection (Differential Mode)
2 kV
ESD (Air Discharge)
8 kV
ESD (Contact Discharge)
4 kV
Interfaces
Interface Type
rj45
Interface Role
downlink
Quantity
8
Max. Link Rate
100 Mbps
PoE Capability
pse
PoE Standards
ieee_802_3af, ieee_802_3at
PoE Output per Port (Max.)
30 W
PoE Output Voltage
52 V
Interface Type
rj45
Interface Role
uplink
Quantity
2
Max. Link Rate
100 Mbps
PoE Capability
none
Interface Type
ac_inlet
Interface Role
power
Quantity
1
Hardware
Product Type
ethernet_switch
Hardware Revision
V1.0
Applicable Technical Scope
eu
Network & Management
Connection Mode
wired
Connectivity Technologies
ethernet
Power Inputs
Power Input Type
ac_mains
Electrical Type
ac
Input Voltage (Min.)
100 V
Input Voltage (Max.)
240 V
Physical
Net Weight
740 g
Environment
Operating Temperature (Min.)
-10 °C
Operating Temperature (Max.)
55 °C
Operating Humidity (Min.)
5 %
Operating Humidity (Max.)
95 %
Storage Temperature (Min.)
-40 °C
Storage Temperature (Max.)
70 °C
Packs & Package Contents
ES-F08PX(1-Pack)
Units per Pack
1
Package Contents
Item Type
product
Quantity
1
Item: ES-F08PX
Item Type
cable
Item
Power Cable
Quantity
1
Item Type
qig
Item
Quick Start Guide
Quantity
1
Item Type
warranty_card
Item
Warranty Card
Quantity
1
