EP-765
PCIe Wi-Fi 7 Network Card · MT7925 BE6500
The EFOCE EP-765 is a PCIe Wi-Fi 7 Network Card · MT7925 BE6500.
Overview
Intro
The EFOCE EP-765 is a PCIe Wi-Fi 7 Network Card · MT7925 BE6500.
Overview
PCIe Wi-Fi 7 Network Card · MT7925 BE6500.
Highlights
- Wi-Fi generation: WIFI 7
- Wi-Fi class: BE6500
- Radio band: band 2 4 ghz; maximum PHY rate 688 Mbps
- Radio band: band 5 ghz; maximum PHY rate 2900 Mbps
- Radio band: band 6 ghz; maximum PHY rate 2900 Mbps
- 1 PCIE host interface(s)
- 1-Pack configuration
Specifications
Wireless
Wi-Fi Generation
wifi_7
Wi-Fi Class
BE6500
Multi-Link Operation (MLO)
yes
4K-QAM
yes
OFDMA
yes
MU-MIMO
yes
Radios
Frequency Band
band_2_4_ghz
Max. PHY Rate
688 Mbps
Spatial Streams
2
Frequency Band
band_5_ghz
Max. PHY Rate
2900 Mbps
Spatial Streams
2
Frequency Band
band_6_ghz
Max. PHY Rate
2900 Mbps
Spatial Streams
2
Interfaces
Interface Type
pcie
Interface Role
host
Quantity
1
Hardware
Product Type
wifi_adapter
Hardware Revision
V1.0
Applicable Technical Scope
eu
Network & Management
Connection Mode
wireless
Connectivity Technologies
wifi, bluetooth
Power Inputs
Power Input Type
pcie_bus
Packs & Package Contents
EP-765(1-Pack)
Units per Pack
1
Package Contents
Item Type
product
Quantity
1
Item: EP-765
Item Type
antenna
Item
External Antenna
Quantity
2
