EAC-7110
Wi-Fi 7 802.11be Tri-Band Access Point · 10775Mbps · 10G SFP+
The EFOCE EAC-7110 is a Wi-Fi 7 802.11be Tri-Band Access Point · 10775Mbps · 10G SFP+.
Overview
Intro
The EFOCE EAC-7110 is a Wi-Fi 7 802.11be Tri-Band Access Point · 10775Mbps · 10G SFP+.
Overview
Wi-Fi 7 802.11be Tri-Band Access Point · 10775Mbps · 10G SFP+.
Highlights
- Wi-Fi generation: WIFI 7
- Radio band: band 2 4 ghz; maximum PHY rate 688 Mbps
- Radio band: band 5 ghz; maximum PHY rate 4323 Mbps
- Radio band: band 6 ghz; maximum PHY rate 5764 Mbps
- 1 RJ45 wan interface(s); maximum link rate 2500 Mbps
- 1 RJ45 lan interface(s); maximum link rate 2500 Mbps
- 1 SFP_PLUS uplink interface(s); maximum link rate 10000 Mbps
- 1 DC_JACK power interface(s)
- 1-Pack configuration
Specifications
Wireless
wifi_7
yes
yes
wpa_personal, wpa2_personal, wpa3_personal
yes
Radios
band_2_4_ghz
688 Mbps
40 MHz
1.7 dBi
4
internal
band_5_ghz
4323 Mbps
240 MHz
4 dBi
4
internal
band_6_ghz
5764 Mbps
320 MHz
4 dBi
4
internal
Interfaces
rj45
wan
1
2500 Mbps
pd
ieee_802_3at
rj45
lan
1
2500 Mbps
sfp_plus
uplink
1
10000 Mbps
dc_jack
power
1
Hardware
wireless_ap
V1.0
eu
1024 MB
128 MB
Network & Management
wireless
ethernet, wifi, fiber
router, access_point
web
yes
yes
384
Power Inputs
dc_input
dc
12 V
12 V
3 A
poe
Physical
550 g
wall, ceiling
indoor
Environment
-10 °C
55 °C
5 %
95 %
-40 °C
70 °C
5 %
95 %
Packs & Package Contents
EAC-7110(1-Pack)
1
Package Contents
product
1
Item: EAC-7110
screws
Mounting Screw
4
qig
Quick Start Guide
1
warranty_card
Certificate & Warranty Card
1
